Hubs

New Sheriff hubs are the ultimate in track racing hubs. They minimize weight with larger cutouts in the flanges, lightened axles, shorter bolts, and slimmer end caps than previous versions. The result is a hubset that weighs a mere 432g, 198g for the front, and 234g for the rear. This makes it one of the lightest track hubsets in the world, a figure even more impressive when you consider that All-City didn't eliminate the usefulness of a fixed / fixed or fixed / free option as most racing hubs do. They feature the finest Japanese manufactured 6902 bearings which roll incredibly fast and smooth while retaining excellent seals for all weather, all-day everyday durability. Front hub specs: - Weight: 198g - Torque Spec: 33nm (25ft lbs.) - Non-Drive Side Center to Flange: 34mm - Drive Side Center to Flange: 34mm - Non-Drive Side Flange Diameter: 62mm - Drive Side Flange Diameter: 62mm Rear hub specs: - Weight: 234g - Torque Spec: 33nm (25ft.lbs.) - Non-Drive Side Center to Flange: 29mm - Drive Side Center to Flange: 29mm - Non-Drive Side Flange Diameter: 62mm - Drive Side Flange Diameter: 62mm

Shimano XT M756 front hub. - Double contact sealing - Super polished bearing races for low friction rolling - Light alloy QR lever and nut - 6-bolt ISO disc mounting surface

Whether your joy comes from barreling downhill, or tearing up to the top, SRAM's MTH 746 rear hub will leave a smile on your face. An aluminum hubshell with machined flanges grant the hub a low weight without compromising durability. Plus, tough cartridge bearings roll smooth for the long haul.

SPANK's new OOZY Trail Hubs are a huge step forward in straight pull hub design and manufacturing. The OOZY Trail Hub has unique oversized straight pull flanges, and a 32H configuration, which vastly improve contact and support between spokes in a 3 cross lacing, offering added spoke strength, wheelset stiffness, and spoke torque retention never before seen in straight pull designs. The SSL (single spoke length) flanges offer ultimate ease and convenience of maintenance. SPANK's end cap system is compatible with SPIKE hubs, and makes conversion between 135 and 142mm rear spacing simple — in QR, 10mm, or 12mm axle diameters. 30T engagement and tried and true 3 pawl system deliver a good blend of quick pick up and trustworthy durability. Like the benefits and techie look of straight pull hubs but not the 28H drawback of traditional designs? Then OOZY Trail Hubs are the answer.

- SPANK's HEX DRIVE 102T technology delivers 3.5° engagement, for almost instant pickup - 6 independent pawls with 3 steps per pawl, work in unison, meaning 18 engagement points per click - Bite-Block Alloy HG and XD Freehub bodies resist damage from cassettes without the weight penalty of steel - Unique flange design reduces dish requirement and minimizes tension range between drive-side and non-drive-side spokes - Advanced seal system improves prevention of bearing/drive system contamination

- Press fit designed to work the hub's non-drive side collar.

Product specs: - Front hub features - 7075 t6 alloy axle - Qr or 15mm axle type - Japanese cartridge bearings - 28,32 hole count - 205g - Rear hub features - 7075 t6 alloy axle - Qr or 12x142mm axle type - Four sealed cartridge bearings - 28,32 hole count - 325g

High flanges builds a stiff, strong wheel - Hubshell is flip-flop version with fixed threading on one side and freewheel threading on the other - Adjustable precision bearings - Knurled stainless steel outer locknut faces - Includes PAUL stainless lockring - Bolt On axle - 290g Dimensions: Axle Spacing: 120mm Flange Diameter: 65mm Center to Flange: 32.5mm Fixed Chainline: 44mm Freewheel Chainline: 48mm

WHY WE MAKE THIS It’s our job to make the best riding hubs in the industry, and 100mm x 12mm front hubs are THE standard for road disc and gravel bikes, so we poured our hearts and souls, not to mention an awful lot of engineering, into this hub. We’re proud of it. WHY YOU WANT IT We already said it was the best, but everybody says that. Our R45 Centerlock™ hubs pair a lightweight hub body with our legendary, made-in-house bearings. The result rolls better, lasts longer, and looks way more handsome than anything else out there. The stiffness of our one-piece axle translates to laser-precise bike handling. This hub also comes in one million (actually a handful) of cool colors. Our bearings, both steel and ceramic, have heat-treated, surgical grade steel races that are machined simultaneously to ensure perfect matching. The quality and speed of our bearings is what you will feel (and hear) on every ride. As Chris King bearing tracks burnish they get actually get faster. A little bit of regular love (i.e. service) will keep this hub rolling for years upon years of demanding use. - Steel Bearings - Engineered, manufactured, and assembled in Portland Oregon - Legendary made-in-house bearings - King Lifetime Warranty - 100mm x 12mm thru axle - Easily serviceable and completely re-buildable with our Universal or R45 Hub Service Tool - Ceramic bearing upgrade available - Available in 24, 28, and 32 hole drillings - Available in Matte finish HUB SPECIFICATIONS Axle Width: 100mm Flange Diameter DS & NDS: 57.4mm Center to Flange DS: 30.6mm Center to Flange NDS: 22.3mm

Reliability meets simplicity—running smoothly day-in and day-out. The 350 hub was developed according to the credo: Reliability meets simplicity. The simultaneous engagement of the ratchets and the resulting large engagement area provide reliability. The plugged construction allows easy maintenance without the need for tools. Adaptation to different axle standards or modification of the engagement angle is also possible with just a few manual steps.

Smooth-rolling performance and 11-speed compatibility define Shimano's 105 rear hub. Shimano's trademark angular contact bearings ensure that your wheels roll as smooth as silk. This hub includes a Shimano quick-release.

At the Center of It All Cast your eyes upon your new favorite component, the infinitely adaptable, fully tuned-and-dialed hub of choice for your custom wheel build. The Vault has almost instant power transfer for slippery-fast speed by way of solid, smart design. Power To The Pedal Let's add it up: a 60-tooth drive ring, 6 pawls, acting in 2 groups of 3, for 120 points of engagement. The result– almost instant transfer of power. Overbuilt But Not Overkill With this hub, bigger is better. An oversized hub shell ads stiffness and stability while large and in-charge 6902 bearings perform for the long run.

- Threaded for multi-speed freewheel (7sp), includes 70mm drum brake - A356 aluminum hub shell with 9mm solid axle (183mm overall axle length) - Freewheel and brake lever sold separately

Shimano Alfine SG-S7001 Disc Brake Internally Geared Hub delivers an impressive gear range, spread across 8 speeds, all with the reliability and low maintenance you can only get with an internally geared hub. - Center Lock Disc Rotor Compatible - Rotor lockring not included - Hub Center to Flange: 30.0mm - Hub Drilling: 32-hole - Flange Diameter: 92.5mm - Drivetrain Speeds: 8 - Spoke Interface: J-Bend

Hope Pro2 Evo Freehub Bodies · Not compatible with Hope Pro2

WHY WE MAKE THIS Originally, we made this hub to be the cornerstone of our hub product line. It was one of those product releases where we put all our hub and bearing experience into, and ended up with a hub that struck that perfect balance between weight, performance, durability and looks. Since the advent of disc brakes (and the R45D), we keep making it, because it’s still that cornerstone hub, and so many of our riders still love to rock their rim brakes on road and off. WHY YOU WANT IT The R45 front hub is lighter and more aerodynamic than most built-to-last hubs on the market. We use a narrow hub body and low flanges to make the R45 a rock solid starting point for any fast wheel build. Our bearings, both steel and ceramic, have heat-treated, surgical grade steel races that are machined simultaneously to ensure perfect matching. The quality and speed of our bearings is what you will feel (and hear) on every ride. As Chris King bearing tracks burnish they get actually get faster. A little bit of regular love (i.e. service) will keep this hub rolling for years upon years of demanding use. -Steel Bearings - Engineered, manufactured, and assembled in Portland, Oregon USA - King Lifetime Warranty - Legendary made-in-house bearings - Easily serviceable with a 2.5mm hex and pick or pen knife - Completely re-buildable with our R45 Hub Service Tool - Available in 28h and 32h - Ceramic bearing upgrade available HUB SPECIFICATIONS - Axle Width: 100mm - Flange Diameter DS & NDS: 39.8mm - Center to Flange DS: 34.8mm - Center to Flange NDS: 34.8mm

- Elite Series convertible road disc hubs - Available in multiple axle configurations - Straight pull and J-bend spoke options - 6 bolt and Center Lock disc brake rotor options - Sealed bearings - Material: AL6061 Straight Pull Spoke/6-Bolt Disc: PCD-L: 36mm PCD-R: 36mm LTF-L: 27.75mm LTF-R: 15.25mm CTF-L: 22.25mm CTF-R: 34.75mm J-Bend Spoke/Centerlock Disc: PCD-L: 45mm PCD-R: 45mm LTF-L: 27.25mm LTF-R: 15.45mm CTF-L: 22.75mm CTF-R: 34.55mm

- Axle/Spacing: 10/14 x 135mm nutted - International Standard 6-bolt disc rotor mount - 11 tooth (1/8") steel cog is pre-installed, ideal for compact drivetrain setup - Tough, instant pickup 120 point triple wedge pawl system with a bushed mini threaded driver for Singlespeed and Dirt Jump - Bushed driver is more durable than cartridge bearings - Forged 6061 aluminum shell, 2 main body sealed cartridge bearings - CrMo M10 bolt-in fittings with 6mm anti-rotation hex fitting (helps when tightening wheel in frame), 14mm adapters included

Shimano XT FH-M756 Series Rear Hub - Double contact bearing seals - Super polished bearing races for low friction rolling - Light alloy QR lever and nut - 6-Bolt rotor mount - Bearing Type: Loose Ball - Cassette Body Type: Shimano/SRAM 8, 9, 10 Speed - Center to Flange, Left: 33.5 - Center to Flange, Right: 20.5 - Flange Diameter Left: 61 - Flange Diameter Right: 61 - Hub Drilling: 32 - Hub/Brake Compatibility: 6-Bolt Disc - Rear Axle: QR x 135mm - Skewer Included: Yes - Spoke Interface: J-Bend - Weight: 495 grams

The DH-UR700-3D Dynamo hub employs a new internal unit construction that is lighter and also reduces dynamo drag while producing 3 watts. It is designed for 26 to 28-inch quick-release wheels. - New internal unit construction is 28g lighter than DH-T8000-3D - More efficient wheel rotation reduces dynamo drag by up to 44% from DH-T8000 - Angular contact bearings - Compact & lightweight - Low rotational resistance - Durable sealing performance

Industry Nine Hydra Classic hubs are the heart of your wheelset, everything revolves around them, literally. Every Classic Hydra hub is made start to finish in Asheville, NC. From turning and milling bar stock 7075-T6 aluminum for shells, axles and encaps, wire EDM cutting A2 tool steel for pawls and driverings, to in-house anodization lab, every step of design, engineering, manufacturing and assembly is done to exacting standards. - 690 P.O.E. Hydra Freehub body engages every .52 degrees yeilding telepathic control - 6 pawl, 6 phase - 115 tooth drivering - Easily serviced with no proprietary tools. Designed to keep you in the saddle and out of the service queue - Classic j-bend spoke interface - Steel cartridge bearings are durable

• Sealed cartridge bearings • High flange design • 120mm hub spacing • Aluminum hub body • Lightweight, hollow, heat-treated axle • Fix/freewheel hub threading • 32 and 26-hole spoke drilling • Bolt-on 3/8-inch axle • Black, silver, or white

The Vandero hub is back and better than ever. This new PRO version of the Vandero is a precision sealed hub with proven in-bound 3/8-inch axle bolts and two plastic guards. Features: - 7075-T6 aluminum hub shell - 6903RS sealed cartridge ball bearings - Precision bored fully concentric bearing seats for a smoother spin and prolonged bearing life - 17mm 7075-T6 aluminum axle with steel helicoil thread inserts - 3/8-inch heat-treated chromoly axle bolts with 17mm wrench flats and a 6mm hex slot - Weight: 11.2oz - Replaceable plastic hub guards included

This is the front hub we want on our bikes. Lightweight, durable, with high quality bearings and seals to give you the best combination of performance, durability and price. This is the new benchmark for a no-nonsense front hub.

Shimano Alfine Center Lock Dynamo Front Hub - Compatible with 26 to 28-inch wheel sizes - Light alloy QR lever and nut - 6V, 3.0W output - Centerlock rotor mount - Spoke Interface: J-Bend - Weight: 575g

This is the rear hub we want on our bikes. A lightweight, durable, ratchet drive hub with high quality bearings and seals to give you the best combination of performance, durability and price. This is the new benchmark for a no-nonsense rear hub.

- CNC alloy thread cover for fixed hubs with 1.37 x 24tpi - Protects bare threads, allows color coordination - Fits both freewheel and fixed-threaded sides (just add the included small washer to fixed side)

Track Front Hub - High polish silver aluminum

Direct power transmission in every riding situation—240 with Ratchet EXP. With the latest generation of the 240 hubs, the strengths have been further enhanced. The latest Ratchet EXP freehub system increases the bearing lifetime thanks to the increased bearing distance. The new version of the end caps simplifies tool-free disassembly and makes maintenance easier. The hollow-machined ratchets transfer your energy directly into acceleration thanks to the 36 teeth.

Aluminum rear hub for bicycle - 18P DBCL 24 holes, straightpull, black. Aluminum Campagnolo freehub body, black. - Dimension: 12x142mm
